Print Font | |
Font | Font A: 9 x 9 Font B: 7 x 9 (default) |
Characters Per Inch | 17.8 cpi / 16 cpi or 14.5 cpi / 13.3 cpi |
Character Size (W x H) | 1.2 mm × 3.1 mm or 1.6 mm × 3.1 mm |
Character Set | 95 Alphanumeric, 48 International, Extended graphics: 128 x 12 pages |
Paper | |
Roll Paper | 76.0 ± 0.5 (W) × dia. 83.0 69.5 ± 0.5 (W) × dia. 83.0 57.5 ± 0.5 (W) × dia. 83.0 |
Overall Dimensions | |
Overall Dimensions (D x W x H) | 160 × 248 × 138.5 mm |
Mass | |
Mass | Approximately 2.3 kg (5.06 lb) |
Standard Accessories | |
Standard Accessories | Dedicated ribbon cassette (ERC-38(B/R)) Roll paper User’s manual AC adapter |
Dot Density | |
Dot Density | 180 dpi x 180 dpi |
Device | |
Two Colour Printing | Yes |
Autocutter | No |
Take Up Device | No |
Wall Hanging Install | Yes |
Interface | |
Interface | RS-232C, Bidirectional parallel, Dealer Option: USB, 10 Base-T I/F |
Reliability | |
MTBF | 180,000 hours |
MCBF | 18 million lines |
Printer Mechanism Life | 7.5 million lines |
Auto Cutter Life | 800,000 cuts (Type A and Type B only) |
Printer Type | |
Print Method | 9-pin serial impact dot matrix |
Print Speed | 4.7 lps (at 40 columns, 16 cpi), 6.0 lps (at 30 columns, 16 cpi) |
Power | |
Power Consumption | Operating: Approx. 38 W (Mean) Standby: Approx. 2.2 W (Mean) |
Power Supply | AC adapter |
Supply Voltage | DC +24 V ± 7% |
Receive Data Buffer | |
Receive Data Buffer | 4 KB or 40 bytes |
