| Print Method |
Impact dot matrix |
| Control Panel |
4 switches and 5 LEDs |
| Print Direction |
Bi-direction with logic seeking |
| Number of Pins in Head |
9 pins |
| Control Code |
ESC/P and IBM PPDS emulation |
| Number of Pins |
9 |
| High Speed Draft |
(10 / 12 / 15 cpi): 347 / 357 / 390 cps
(Condensed, 17 / 20 cpi): 383 / 298 cps |
| Draft |
(10 / 12 / 15 cpi): 260 / 312 / 223 cps
(Condensed, 17 / 20 cpi): 222 / 260 cps
(Emphasized, 10 cpi): 130 cps |
| NLQ |
(10 / 12 / 15 / 17 / 20 cpi): 65 / 78 / 55 / 47 / 56 cps |
| Printhead Life |
Approx. 400 million strokes/wire |
| Mean Print Volume Between Failure (MVBF) |
Approx. 20 million lines (Except print head) |
| Mean Time Between Failure (MTBF) |
Approx. 10,000 POH (25% Duty) |
| Character Sets |
Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portugese), PC861 (Icelandic), PC863 (Canadian French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15 |
| Bitmap Fonts |
Epson Draft: 10, 12, 15 cpi; Epson Roman & Sans Serif: 10, 12, 15 cpi, Proportional, Epson OCR-B |
| Barcode |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet |
| Manual Insertion |
Rear in, Top out |
| Push Tractor |
Rear in, Top out |
| Cut Sheet (Single Sheet) |
Length: 100 ~ 364mm (3.9 ~ 14.3")
Width: 100 ~ 257mm (3.9 ~ 10.1")
Thickness: 0.065 ~ 0.14mm (0.0025 ~ 0.0055") |
| Cut Sheet (Multi-part Forms) |
Length: 100 ~ 364mm (3.9 ~ 14.3")
Width: 100 ~ 257mm (3.9 ~ 10.1")
Thickness: 0.12 ~ 0.39mm (0.0047 ~ 0.015") (Total) |
| Continuous Paper (Single Sheet / Multi-part) |
Length: 101.6 ~ 558.8mm (4.0 ~ 22.0")
Width: 101.6 ~ 254.0mm 4.0 ~ 10.0")
Thickness: 0.065 ~ 0.39mm (0.0025 ~ 0.015") (Total) |
| Envelope (No.6) |
Length: 92mm (3.6")
Width: 165mm (6.5")
Thickness: 0.16 ~ 0.52mm (0.0063 ~ 0,0205") (Total) |
| Envelope (No.10) |
Length: 105mm (4.1")
Width: 241mm (9.5")
Thickness: 0.16 ~ 0.52mm (0.0063 ~ 0.0205") (Total) |
| Roll Paper |
Width: 216mm (8.5")
Thickness: 0.07 ~ 0.09mm (0.0028 ~ 0.0035") |
| Supported OS |
Microsoft® Windows® 2000 / XP / Vista / 7 / 8 / 8.1 / 10 |
| Dimensions (W x D x H) |
362 x 275 x 154 mm |
| Weight |
Approx. 4.1 kg |
| Ribbon Cartridge Black |
Ribbon Life: Approx. 4.0 million characters (Draft 10 cpi, 14 dots/character) |
| Temperature |
5 ~ 35°C |
| Humidty |
10 ~ 80 % RH |
| Acoustic Noise |
Approx. 53 dB(A) (ISO 7779 pattern) |
| Input Data Buffer |
128KB |
| Standard |
Bi-directional parallel (IEEE-1284 nibble mode supported)
USB 2.0 Full-Speed
Serial |
| Standard |
Fabric Ribbon Cartridge (Black) - C13S015632 |
| Ribbon Life |
Approx. 4.0 million characters (Draft 10 cpi, 14 dots/character |
