| Printer |
| Maximum Printing Resolution |
4800 (horizontal) x 1200 (vertical) dpi |
| Print Head / Ink |
Number of Nozzles: Total 1,472 nozzles |
| Ink Bottles |
GI-790 (Black, Cyan, Magenta, Yellow) |
| Print Speed (ISO/IEC 24734) |
- Document: Col ESAT/Simplex: 5.0 ipm
- Document: Mono ESAT/Simplex: 8.8 ipm
- Photo (4 x 6") PP-201/Borderless: 60 sec |
| Printable Width |
Bordered: Up to 203.2 mm (8 inch), Borderless: Up to 216 mm (8.5 inch) |
| Printable Area |
- Borderless Printing: Top/Bottom/Right/Left margin: 0 mm
- Bordered Printing: Top: 3 mm, Bottom: 5 mm, Left/Right: 3.4 mm (Letter/Legal: Left: 6.4 mm, Right: 6.3 mm) |
| Recommended Printing Area |
Top margin: 31.2 mm, Bottom margin: 32.5 mm |
| Paper Size |
A4, A5, B5, Letter, Legal, 4 x 6", 5 x 7", 8 x 10", Envelopes (DL, COM10), Square (5 x 5"), Business Card, Custom size (width 55 - 215.9 mm, length 89 - 676 mm, *F4 is possible via custom size settings) |
| Paper Handling (Rear Tray) |
| Maximum Number |
- Plain Paper: A4, A5, B5, Letter = 100, Legal = 10
- High Resolution Paper (HR-101N): A4, Letter = 80
- Photo Paper Plus Glossy II (PP-201): A4, Letter = 10, 4 x 6" = 20, 5 x 7", 8 x 10" = 10, Square (5 x 5") = 20
- Photo Paper Plus Semi-Gloss (SG-201): A4, Letter = 10, 4 x 6" = 20, 5 x 7", 8 x 10" = 10
- Matte Photo Paper (MP-101): A4, Letter = 10, 4 x 6" = 20
- Envelope: European DL/US Com. #10 = 10
- Photo Paper Plus Glossy II (PP-208): A4, 4 x 6" = 10
- Photo Sticker: PS-208, PS-808 = 1 |
| Paper Weight (Rear Tray) |
Plain Paper: 64 - 105 g/m2, Canon specialty paper: Max. 275 g/m2 Photo Paper Plus Glossy II (PP-201) |
| Ink End Sensor |
Dot count |
| Print Head Alignment |
Manual |
| System Requirements |
- Windows: Windows 10, Windows 8.1, Windows 7 SP1
- Macintosh: Mac OS is not supported |
| General Specifications |
| Interface |
USB 2.0 |
| Paper Output Tray |
A4, Letter = 50, Legal = 10 |
| Operating Environment |
Temperature: 5 - 35°C, Humidity: 10 - 90% RH (no dew condensation) |
| Recommended Environment |
Temperature: 15 - 30°C, Humidity: 10 - 80% RH (no dew condensation) |
| Storage Environment |
Temperature: 0 - 40°C, Humidity: 5 - 95% RH (no dew condensation) |
| Quiet Mode |
Available |
| Acoustic Noise (PC Print) |
Plain Paper (A4, Mono): Approx. 54.5 dB(A) |
| Power |
AC 100 - 240 V; 50/60 Hz |
| Power Consumption (Approx.) |
Connection to PC: USB
OFF: 0.2 W, Standby (scanning lamp is off): 0.6 W
Copying (G1010): 11 W |
| Dimensions (W x D x H) |
Factory configuration: 445 x 330 x 135 mm, Output/ADF Trays Extended: 445 x 529 x 253 mm |
| Weight (Approx.) |
4.8 kg |
