Main Input Voltage | 230 V |
Main Output Voltage | 230 V |
Rated power in W | 360 W |
Rated power in VA | 650 VA |
Input Connection Type | NEMA 5-15P |
output connection type | 4 NEMA 5-15R |
Cable length | 1.22 m |
Number of cables | 1 |
Battery type | Lead-acid battery |
Provided equipment | User manual |
Battery recharge time | 8 h |
Battery voltage | 12 V |
Redundant | No |
UPS size | WS |
Colour | Black |
height | 14.2 cm |
Width | 10.1 cm |
Depth | 30 cm |
Net weight | 4.2 kg |
Mounting preference | No preference |
Mounting mode | Not rack-mountable |
USB compatible | No |
Mounting position | Vertical |
Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
Input voltage limits | 140...300 V |
Input protection type | Circuit breaker |
Maximum configurable power in W | 360 W |
Output frequency | 50/60 Hz +/- 1 Hz sync to mains |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
Graph display | 1 |
Maximum configurable power in VA | 650 VA |
Transfer time | 6 ms typical : 10 ms maximum |
Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Ambient air temperature for operation | 0…40 °C |
Relative humidity | 0…95 % non-condensing |
Operating altitude | 0...3000 m |
Ambient air temperature for storage | -15…40 °C |
Storage Relative Humidity | 0…95 % non-condensing |
Storage altitude | 0…15000 m |
Acoustic level | 40 dBA |
IP degree of protection | IP20 |
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge energy rate | 156 J |
Unit Type of Package 1 | PCE |
Number of Units in Package 1 | 1 |
Package 1 Height | 23.3 cm |
Package 1 Width | 34.7 cm |
Package 1 Length | 14.3 cm |
Package 1 Weight | 4.42 kg |
